Php 1,995,000 - 2,295,000

Prices may change without prior notice.

Discover the newly designed Grand Carnival.




Engine Type

‎In-line 4-Cylinders, CRDi, DOHC, 16V, Variable Geometry Turbo with Intercooler

Max Power

193 ps @ 3,800 rpm

Max Torque

45 kg-m @ 1,750-2,750 rpm




6-Speed AT with Sport mode


MacPherson Strut with Stabilizer and Multi-link (Front) / Gas Type Shock Absorbers (Rear)


235 / 60 R18 Alloy
Note: Specs shown are for the Top-of-the-Line (Car Brand, Car Model). Full and detailed specs are shown below.

Available Colors

Price List

Variant Price
Grand Carnival 2.2 CRDi EX (11-Seater) AT ₱2,180,000
Grand Carnival 2.2 CRDi EX (7-Seater) AT ₱2,295,000
Grand Carnival 2.2 CRDi LX (11-Seater) AT ₱1,995,000
View KIA pricelist

Full Specification

7-Seater LS 7-Seater 11-Seater
Overall Length x Width x Height (mm) 5,115 x 1,985 x 1,755 5,115 x 1,985 x 1,767
Wheelbase (mm) 3,060
Wheel Tread (mm) 1,740 / 1,747
Minimum Ground Clearance (mm) 171
Gross Vehicle Weight (kg) 2,830 3,045
Fuel Tank Capacity (ltr) 80
7-Seater LS 7-Seater 11-Seater
Description 2.2L Turbo Charged Inter-cooler (VGT), Diesel, Euro 4 Compliant
Displacement (cc) 2,199
Maximum Output (ps/rpm) 200 / 3,800
Maximum Torque (kg.m/rpm) 45 / 1,750~2,750
7-Seater LS 7-Seater 11-Seater
Transmission FWD 6-Speed, Automatic Transmission with Sports Mode
Brakes Front 17-inch Ventilated Discs
17-inch Solid Discs
Suspension (Front / Rear) MacPherson Strut with Stabilizer and Multi-link / Gas Type Shock Absorbers
Tire Size 235 / 60 / R18
Wheel Type Alloy
Spare Tire Temporary (Steel)
7-Seater LS 7-Seater 11-Seater
Airbag Dual
ABS Equipped
Remote Keyless Entry with Alarm Equipped
High Mount Stop Light Standard; LED Type
Rear Parking Assist Equipped; With Rear View Camera
Child Anchor Standard: ISOFIX
7-Seater LS 7-Seater 11-Seater
Antenna Shark Fin Type
Foglamps Standard
Headlamps Projector Type with Escort Function
Surround DLO Chrome
Radiator Grille High Glossy Black with Chrome (Bar Type) Black (Bar Type)
Front Wiper Aero Blade Conventional
Rear Spoiler Standard with HMSL
Rear Combination Lamps Standard; LED Type
Roof Rack Standard
Sunroof Standard + Dual -
7-Seater LS 7-Seater 11-Seater
Aircon Dual Full Auto Climate Control Manual Type
Seat Material Leather Cloth
Shift Knob Leather Standard
Seats Front Sliding, Reclining, Lifter (Driver side only), Adjustable Headrest
2nd Row
Sliding, Reclining, Folding, Stand-up (Pilot Seats) Sliding, Reclining with Jump Seat
3rd Row
Reclining, Folding, 60:40 Split Sinking Sliding, Reclining, Folding with Jump Seat
4th Row
Bench Type, Pop-up, Sinking
Steering Wheel Leather, Tilt Adjust + Telescopic Poly Urethane, Tilt Adjust + Telescopic
Cup Holder Standard; With Cover
Center Arm Rest Standard (Storage Box)
Dr/Pas Sunvisor With Vanity Mirror (Illuminated)
Over Head Console Lamp With Conversation Mirror
Power Outlet Standard; Center Front and Rear
USB Charger Standard; Center Front and Rear
7-Seater LS 7-Seater 11-Seater
Power Steering Hydraulic (HPS)
Standard (Auto Down; Driver Side Only)
Outside View Mirrors
Folding with Side Repeater + Electric Adjustable + Heated
Door Locks
Driver + Passenger
Sliding Doors
Door Lock System Smart Key with Push Start/Stop Button Smart Key
Tail Gate Smart Power Manual Type
Audio System AM/FM Radio, CD, MP3, Aux-in & USB Ports,iPod Ready, Bluetooth, Touch Screen with 6 speakers AM/FM Radio, CD, MP3, Aux-in& USB Ports, iPod Ready, TouchScreen with 6 speakers
Audio Contro Steering Wheel Mounted
Cruise Control Steering Wheel Mounted
Rheostat Standard
Trip Computer Standard
Autolight Control Standard
Eco Mode Standard
Glove Box Standard; With Illumination + Cooling
